制冷液压全自动真空滚揉机

Refrigeration hydraulic fully automatic vacuum rolling and kneading machine

一、设备简介

LYGR系列制冷滚揉机采用循环制冷系统，转动支架，卧式液压倾斜滚揉。相比其他型，具有制冷滚揉性能，能保证物料的在滚筒内的温度从而提升滚揉效果，有更大的装载能力和更方便地卸料性能。变频无级调速，速度范围2-12rpm（可以选择1-4rpm低速功能。）；启动平稳，降低机器启动时的冲击，延长设备使用寿命。专门配置辅料真空吸管。采用触摸屏控制，满足多样性产品的加工要求。高标准的卫生设计。整机采用SUS304优质不锈钢材料；滚揉桶内部精细抛光，无卫生死角，卸料位置能彻底排水。可选的“V型”和“单片型”桨叶，不同的滚揉力度，适应不同的产品。采用减速机直连驱动，运行躁声更低，效率更高。

一、Product function

LYGR series rolling and kneading machine adopts a rotating bracket and horizontal hydraulic inclined rolling and kneading.  Compared with other models, it has greater loading capacity and more convenient unloading performance.  Inverter stepless speed regulation, speed range of 2-12rpm (the low-speed function can be selected from 1-4rpm.); it starts smoothly, reduces the impact during start-up of the machine and extends the service life of the equipment.  Specially equipped with auxiliary material vacuum straws.  Use touch screen control to meet the processing requirements of diverse products.  High standard hygiene design.  The whole machine is made of SUS304 high-quality stainless steel material; the inside of the rolling and kneading barrel is finely polished, without sanitary dead corners, and the discharge position can be completely drained.  Optional "V-shaped" and "mono-piece" paddles with different rolling and kneading strengths to adapt to different products.  Directly connected to the reducer is used to drive, which has lower operating noise and higher efficiency.  Compared with the YGR model, the refrigeration circulation system is added, which ensures the temperature of the material in the drum, making the material pickling effect better.
